Industrial Compliant Wireless LAN

Compliant with the IEEE 802.11a/b/g/n/ac/ax wireless technology
Equipped with 10/100/1000Mbps RJ45 ports, and auto MDI/MDI-X


RF Interface Characteristics

802.11ax 2T2R architecture with data rate of up to 3000Mbps (600Mbps in 2.4GHz and 2400Mbps in 5GHz)
High output power with multiply-adjustable transmit power control


Multiple Operation Modes and Wireless Features

Multiple operation modes: AP, gateway and repeater
Supports OFDMA (orthogonal frequency division multiple access)
Supports MU-MIMO (multi-user multiple-input multiple-output), Beamforming and BSS Coloring
WMM (Wi-Fi multimedia) provides higher priority to multimedia transmitting over wireless
Coverage threshold to limit the weak signal of clients occupying session
Real-time Wi-Fi channel analysis chart and client limit control for better performance
Support Terminal Seamless Roaming with 802.11k, 802.11v, and 802.11r
Supports Mesh connection


Secure Network Connection

Full encryption supported: WPA3 Personal, WPA2/WPA3 Personal, WPA2 Personal (AES), WPA2 Personal (TKIP), WPA2 Personal (TKIP+AES), WPA/WPA2 Personal (AES), WPA/WPA2 Personal (TKIP), WPA/WPA2 Personal (TKIP+AES), WPA2 Enterprise, WPA/WPA2 Enterprise
Supports 802.1Q port VLAN Supports IP/Port/MAC address/URL filtering, DoS, SPI firewall
Supports DMZ and port forwarding
Bandwidth control per IP address to increase network stability


Easy Deployment and Management

Support management by PLANET CloudViewer and CloudViewerPro app
Supports PLANET AP Controllers in AP mode
Easy discovery by PLANET Smart Discovery
Self-healing mechanism through system auto reboot setting
System status monitoring through remote syslog server
Gateway mode supports PLANET DDNS/Easy DDNS, Captive Portal, RADIUS Server/Client
